SPECIFICATIONS IN DETAIL
We always quote 'real world' performance figures (measured to the AES17 standard). Some companies choose to quote chipset performance, which is misleading, and here's why.
SUPPORTED SAMPLE RATES
44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
MICROPHONE INPUTS
- Frequency Response-
- 20Hz - 20kHz +0.5/-1.5dB
- Dynamic Range-
- 109 dB (A-Weighted)
- THD+N-
- <0.001%
- Noise EIN-
- -127 dBu
- Maximum input level (without pad)-
- +8 dBu
- Maximum input level (with pad)-
- +16 dBu
- Gain Range-
- 50 dB
- Input Impedance-
- 3 kΩ
LINE INPUTS
- Frequency Response-
- 20Hz - 20kHz +0.5/-1.5dB
- Dynamic Range-
- 109 dB (A-Weighted)
- THD+N-
- <0.002%
- Maximum input level-
- +22 dBu
- Gain Range-
- 50 dB
- Input Impedance-
- 49 kΩ
INSTRUMENT INPUTS
- Frequency Response-
- 20Hz - 20kHz +0.5/-1.5dB
- Dynamic Range-
- 108 dB (A-Weighted)
- THD+N-
- <0.01%
- Maximum input level-
- +13 dBu
- Gain Range-
- 50 dB
- Input Impedance-
- 1 MΩ
LINE OUTPUTS
- Maximum Output Level (0 dBFS)-
- +16dBu @ 0dBFS, or >21dBu where ADAT output is not used
- THD+N-
- <0.001%
- Ouput Impedance-
- 136 Ω (Balanced) - for units with serial number ≤ W860083007515
- 576 Ω (Balanced) - for units with serial number > W860083007515
